Informações do Produto
Características
ESPECIFICAÇÕES TÉCNICAS | DIMENSÕES
Câmera
Sensor de Imagem:
1/2.8" Progressive Scan CMOS
Sistema do Sinal:
PAL/NTSC
Iluminação Mín.:
Color: 0.005 lux @(F1.2, AGC ON), 0 lux with IR
Velocidade do Obturador:
1/3 s to 1/100,000 s
Obturador Lento:
Support
Lentes:
2.8 mm, horizontal field of view: 108°
4 mm, horizontal field of view: 86.4°
6 mm, horizontal field of view: 52°
8 mm, horizontal field of view: 40°
12 mm, horizontal field of view: 25°
Montagem de Lente:
M12
Faixa de ajuste:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Dia e Noite:
IR cut filter with auto switch
Ampla Abertura Dinâmica (WDR):
120 dB
Redução Digital de Ruído (DNR)::
3D DNR
Padrão de Compressão
Taxa de bits de Vídeo:
32Kbps~16Mbps
Terceira Transmissão:
Yes
Imagem
Resolução Máx. de Imagem:
1920 x 1080
Taxa de Quadros:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280×720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280×720)
Transmissão secundária:
50Hz: 25fps (640 × 360, 352 × 288)
60Hz: 30fps (640 × 360, 352 × 240)
Terceira Transmissão:
50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240)
Aprimoramento de Imagem:
BLC/3D DNR
Configurações de Imagem:
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Corte Regional:
Support
ROI:
Support 1 fixed region for each stream, and face dynamic tracking
Seleção Dia/Noite:
Auto/Scheduled
Rede
Protocolos:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Funções Gerais:
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access
Compatibilidade do Sistema:
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Interface de Comunicação:
1 RJ45 10M / 100M Ethernet interface
Armazenamento Interno:
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Funções Inteligentes
Detecção de Cruzamento de Linha:
Cross a pre-defined virtual line
Detecção de Intrusão:
Enter and loiter in a pre-defined virtual region
Bagagens Abandonadas:
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Objeto Removido:
Objects removed from the pre-defined region, such as the exhibits on display.
Itens Gerais
Condições de funcionamento:
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Fonte de Alimentação:
12 VDC ± 25%, PoE (802.3af Class3)
Consumo de Potência:
12 VDC ± 25%, 5W
PoE(802.3af, class 3), 6.5W
Grau de Proteção:
IP67
Distância do IR:
Up to 30m
Dimensões:
Camera: Φ70 × 155.03 mm (Φ2.76″ × 6.1″)
Package: 216 × 121 × 118 mm (8.5″ × 4.76″ × 4.65″)
Peso:
Camera: 410 g (0.9 lb.)
